outer diameter:2mm-6mm
inner dameter:0.8mm-1.5mm
thickness:0.65mm-1.1mm
angle:60-165
As a tool for glass cutting, the diamond scribing wheel is the primary factor to decide the cutting quality of the glass. The diamond scribing wheel features stable function, sharp cutting edge, precise cutting angle, and precise roundness and thickness of the bore. These features guarantee the excellent cutting quality.
Items | Specifications | |||
OD(mm) | ID(mm) | T(mm) | V(°) | |
Standdard Carbide | 2.00 | 0.8 | 0.65 | 60-165 |
2.50 | 0.8 | 0.65 | ||
3.00 | 0.8 | 0.65 | ||
3.20 | 1.2 | 1 | ||
4.10 | 1.3 | 1 | ||
4.10 | 1.4 | 1.1 | ||
5.00 | 1.4 | 1.1 | ||
6.00 | 1.5 | 1.1 | ||
6.00 | 1.5 | 1.1 | ||
Other Size could be customed as per drawing. | ||||
Application:
1. TFT-LCD, AMOLED touch panel(such as TV), glass thickness: 0.4-0.7mm
2. TFT-LCD, AMOLED touch panel(such as smartphone, Pad), glass thickness: 0.15-0.25mm
3. Substrate glass(mother glass), glass thickness:0.15-1.1mm
4. Cover glass, glass thickness: 0.4-1.1mm
